Angle steel

Ruixiang Steel offers a comprehensive range of high-performance Angle Steel, also known as L-profiles. Our angle bars are available in both Equal Angle and Unequal Angle configurations, manufactured from premium carbon structural steel through a precision hot-rolling process. Our products are widely utilized in telecommunication towers, power supports, warehouse racking systems, and architectural frameworks. All products comply with international standards, including ASTM A36, JIS G3192, and EN 10025, and can be supplied with hot-dip galvanizing treatment to ensure superior corrosion resistance.

Cases:

Enquiry

PDF Download

Structural Angle Steel (Equal & Unequal)

Name: Structural Angle Steel (Equal & Unequal)
Brand: Ruixiang Steel
Availability: InStock
Rating: 4.9 (215 reviews)

Ruixiang Steel is a leading manufacturer of high-strength Angle Bars. We provide premium Hot Rolled and Hot-Dip Galvanized (HDG) profiles compliant with ASTM A36, S235JR, and S355JR for critical structural reinforcement.

Advanced Manufacturing & Customization

Hot-Dip Galvanizing (HDG)

Coating weights from Z275 to Z600. Our galvanizing process provides a maintenance-free service life of 20-50 years in coastal or industrial environments.

CNC Precision Fabrication

Save on-site labor with our CNC drilling, punching, and mitre cutting services, ensuring 100% alignment with your structural blueprints.

Technical Specifications

Category	Detailed Parameters
Type	Equal Angle (L-Bar) & Unequal Angle
Size Range	20mm x 20mm to 250mm x 250mm
Thickness	3.0mm – 24.0mm
Steel Grades	Q235B, Q355B, A36, S235JR, S355JR, SS400
Length	6m, 9m, 12m or custom precision cutting
Surface Options	Black/Mill Finish, Hot-Dip Galvanized, Painted

Angle Steel FAQ

Q: When should I use Unequal Angle steel instead of Equal Angle?

A: Unequal angles are used when structural loads are significantly different on two axes, such as in lintels, specialized machinery frames, or where weight reduction is needed without sacrificing strength on the primary load-bearing side.

Q: Do your galvanized angles meet the ASTM A123 standard?

A: Yes. All our hot-dip galvanized angle steel is treated in accordance with ASTM A123 (for structural items) or ISO 1461, ensuring a metallurgical bond and uniform zinc thickness.
