Cold rolled coil

Carbon steel is an iron-carbon alloy with carbon content ranging from 0.0218% to 2.11%. Also known as carbon steel. Generally also contains a small amount of silicon, manganese, sulfur, phosphorus. The higher the carbon content of general carbon steel, the greater the hardness, the higher the strength, but the lower the plasticity.

Cases:

Enquiry

PDF Download

Cold Rolled Steel Coil (CRC) Manufacturer

Name: Cold Rolled Steel Coil (CRC) - SPCC/DC01/ST12
Brand: Ruixiang Steel
Availability: InStock
Rating: 4.9 (168 reviews)

Ruixiang Steel delivers high-precision Cold Rolled Coils characterized by superior surface integrity and excellent deep-drawing properties. Compliant with JIS G3141, EN 10130, and ASTM A1008, our CRC is the preferred choice for automotive, appliance, and furniture manufacturing.

Technical Specifications

Parameter	Standard Range
Thickness Range	0.2mm – 3.0mm (Precision: ±0.02mm)
Width Range	50mm – 1500mm (Standard: 1000mm, 1219mm, 1250mm)
Material Grades	SPCC, SPCD, SPCE \| DC01, DC03, DC04, DC05, DC06 \| ST12, ST13
Surface Finish	Bright (G), Matte (D), Stone (S), Oiled/Unoiled
Coil ID / Weight	ID: 508mm/610mm \| Coil Weight: 3 – 8 Tons
Standards	JIS G3141, DIN 1623, EN 10130, ASTM A1008, GB/T 11253

Why Source CRC from Ruixiang Steel?

Superior Surface Quality

Our CRC undergoes advanced annealing and temper rolling, providing a bright, smooth surface ideal for high-end painting, galvanizing, or chrome plating.

Exceptional Formability

Grades DC04 to DC06 offer extreme deep-drawing capabilities, perfect for complex automotive body parts and intricate appliance panels.

Export Standard Packaging

4-layer protection: Plastic film + Anti-rust Kraft paper + Galvanized steel cover + Steel strapping for 100% rust prevention.

Cold Rolled Coil FAQ

Q: What is the shelf life of oiled cold rolled coils?

A: When stored in a dry, ventilated warehouse with our standard heavy oiling, the surface will remain rust-free for 6-12 months. Unoiled or lightly oiled coils should be processed within 1 month.

Q: How do I choose between DC01 and DC04?

A: DC01 is for general structural use and simple bending. DC04 is an "Extra Deep Drawing" grade with higher elongation, required for complex stamping where the steel needs to stretch without tearing.

Cold rolled coil

Cold-rolled plate

Ruixiang Steel specializes in manufacturing high-precision Cold Rolled Steel Plates (CRC Sheets). Our cold rolling process involves further thinning hot-rolled sheets at room temperature to achieve superior surface smoothness and tighter thickness tolerances. These plates are favored for applications requiring high aesthetic quality and excellent formability, such as automotive body parts, electronic enclosures, and hardware tools.Carbon steel is an iron-carbon alloy with carbon content ranging from 0.0218% to 2.11%. Also known as carbon steel. Generally also contains a small amount of silicon, manganese, sulfur, phosphorus. The higher the carbon content of general carbon steel, the greater the hardness, the higher the strength, but the lower the plasticity.
